Revolt RVX Official Specifications: The Complete, Verified Spec Sheet (2026)
Spec aggregator sites frequently show conflicting numbers for the same electric motorcycle, we've seen this problem firsthand researching other bikes for this blog. To avoid that here, this article presents the Revolt RVX's specifications exactly as they appear on the manufacturer's official, signed specification documentation, with every claimed figure clearly marked.
Performance
Segment: Sports
Top Speed (Boost Mode): 90 Kmph*
Mode-Specific Top Speeds: Boost 90 Kmph, Sports 80 Kmph, City 65 Kmph*, Eco 50 Kmph*
Peak Motor Rating: 5.3 kW
Motor Type: Mid Drive PMSM
Max Torque (At Motor): 50 Nm
Max Torque (At Wheel): 230 Nm
Acceleration (0-40 Kmph): 3.9 Sec*
Gradability (1 Person): 14 Deg.*
Gradability (2 Persons): 11.5 Deg.*
IP Rating (Motor & Controller): IP67
Drive System: Chain Drive, Front Sprocket 13T, Rear Sprocket 60T, Chain 120L
Battery
Capacity: 3.24 kWh
Functionality: Removable
Chemistry: NMC
Cooling System: Passive
IDC Range: 160 Km/Charge*
IP Rating (Battery Pack): IP67
Warranty: 8 Years or 80,000 km, whichever comes first
Charging
Charging Time (0-80%): 3 Hrs 30 Mins
Charger Type: Offboard
Charger Rating: 10 A
Fast Charging Time (0-80%, optional): 80 Mins
Fast Charging Rating: 27 A
Tyres and Wheels
Wheel Type: Alloy
Front Wheel Rim Size: MT 2.15 x 17
Rear Wheel Rim Size: MT 3.00 x 17
Front Tyre: 90/80 - 17, Tubeless
Rear Tyre: 110/80 - 17, Tubeless
Ground Clearance: 190 mm
Brakes and Suspension
Braking System: CBS (Combined Braking System)
Brake Type: Front Disc, Rear Disc
Front Suspension: Upside Down Fork
Rear Suspension: Monoshocker
Dimensions
Kerb Weight: 117 Kgs
Payload Capacity: 150 Kgs
Overall Dimensions (L x W x H): 2040 x 710 x 1073 mm
Wheel Base: 1340 mm
Seat Height: 815 mm
Electrical and Cluster
Lighting: LED (headlight, DRL, tail light, indicators)
Vehicle Start System: Push Button with Remote Key
Screen Size: 3.5 Inch
Display Type: PMVA (Colour)
Smart Features
Mobile App Connectivity: Yes
GPS: Yes
Bluetooth Connectivity: Yes
Geo-Fencing: Yes
OTA Updates: Yes
Immobilization (Remote Vehicle On/Off): Yes, Limited
Vehicle Locator: Yes
Reverse Mode: Yes
Hill Hold: Yes
Walk Assist: Yes
Boost Mode: Yes
Call/Message Alerts on Cluster: Yes
Seat & Handle Lock: Manual Key
Colour Options
